Bi-Parting TopBlind

TopShade Bi Parting TopBlind L 007

We have the Bi-Parting TopBlind for the larger Skylights. This is a variation on the TopBlind L and the TopBlind XL. The two screens connect seamlessly with each other and ensure perfect sun protection for the larger Skylights.

Depending on the required size, either the TopBlind L or the TopBlind XL will be suitable for this. Which type you need is therefore determined by the size of the Skylight.

Standard Fabric

white 92-2044	boulder 92-2171	alu/anthracite 92-2068
alu/white 92-2051	beaten metal 92-2045	cloud 92-50272
alu/oat 92-2046	concrete 92-2167	tennis green 92-8056
alu/alu 92-2048	alu/medium grey 92-2074	anthracite 92-2047
quartz 92-50303	champagne 92-2175	hemp 92-50265
pepper 92-2012	gold 92-50273	havana-brown 92-50266
bronze 92-2043	beetle 92-2149	snow white 92-50690
shea 92-50843	moss green 92-2158	taupe 92-50850
dark grey 92-51177	aniseed 92-2157	celestial grey 92-51178
green-grey 92-51179	buttercup 92-2166	orange 92-8204
copper 92-50274	brick 92-51180	deep red 92-51181
deep blue 92-51182	deep black 92-51176	red 92-8255
lagoon 92-2160	sandy beige92-2135

Blackout Fabric

white B92-1044	boulder B92-2171	sandy beige B92-2135
alu B92-1046	beaten metal B92-1045	bronze B92-1043
deep black B92-51176

technical specifications

	value	standards
weight	420 g/m2	EN ISO 2286-2
thickness	0.45 mm	-
wi dth	177 cm - 267 cm	-
standard format length	50 lm in 177 cm width / 40 lm in 267 cm width	-
tensile strength (warp/weft)	310/210 daN/ 5 cm	EN ISO 1421
tear strength (warp/weft)	45/20 daN	DIN 53.363
flame retardancy	B-s2,d0/EN 13501-1 M1/NFP 92-507 • B1/DIN 4102-1• BS 7837 • BS 5867 • Schwerbrennbar Q1-Tr1/ ONORM A 3800-1 • Classe 1/UNI 9177-87 • M1/UNE 23.727-90 • VKF 5.3/SN 198898 •1530.3/AS/NZS • G1/GOST 30244-94 • Method 1/NFPA 701 • CSFM T19 • Class A/ASTM E84 • Group 1/AS/NZS 3837 • Class 1/EN 13773 • CAN/ULC-S109	-
warranty	5 years	-
