The TopBlind L

The TopBlind L is the first model that we have launched on the market for horizontal window systems. This model is extremely suitable for medium sizes up to approximately 3000mm x 2500mm.

The ideal solution for rooms that get very warm in the summer.

Because the TopBlind L is close to the window, practically no sunlight enters. During the day it is possible to look through the cloth from the inside to the outside. So it does not give a closed-in feeling.

The TopBlind L is sleek and has a slim beveled cassette. Due to its small cassette size (95mm x 95mm) it fits perfectly with smaller horizontal windows and roof hatches.

The TopBlind L is supplied as standard in the colour RAL7015, but of course all other standard RAL colours are also available and this does not affect the price.

We always use the Soltis Perform 92 for the cloth, this is a pre-stretched cloth specially designed for horizontal use. This cloth will sag less quickly than the other cloths.
It is also possible to choose a completely blackout cloth, but the maximum size for this is 3M2.

There are various cloth colours available in the Soltis Perform 92 series. Make your choice in the colour range which you can find here.

TopShade Montage 001 PNG

The Topblind L is supplied with a Somfy io motor incl. remote control but it is also possible to operate the Topblind L by your home automation system. Please indicate this with your order so that we can install the correct motor in your system.

TopShade also has the option of supplying a home automation system.

This system can be linked to Google Home or Siri, among others. This allows these systems to be easily operated by means of an app on your phone or by means of your voice.


Features:

  • Heat and light resistant
  • Entry-level vertical sun protection
  • Favorable price-quality ratio
  • Extensive choice in appearance


Maximum dimensions:

Width Height
3000 mm 2000 mm
2000 mm 2500 mm

request information directly here






white 92-2044

boulder 92-2171

alu/anthracite 92-2068

alu/white 92-2051

beaten metal 92-2045

cloud 92-50272

alu/oat 92-2046

concrete 92-2167

tennis green 92-8056

alu/alu 92-2048

alu/medium grey 92-2074

anthracite 92-2047

quartz 92-50303

champagne 92-2175

hemp 92-50265

pepper 92-2012

gold 92-50273

havana-brown 92-50266

bronze 92-2043

beetle 92-2149

snow white 92-50690

shea 92-50843

moss green 92-2158

taupe 92-50850

dark grey 92-51177

aniseed 92-2157

celestial grey 92-51178

green-grey 92-51179

buttercup 92-2166

orange 92-8204

copper 92-50274

brick 92-51180

deep red 92-51181

deep blue 92-51182

deep black 92-51176

red 92-8255

lagoon 92-2160

sandy beige92-2135








value

standards

weight

420 g/m2

EN ISO 2286-2

thickness

0.45 mm

-

wi dth

177 cm - 267 cm

-

standard format length

50 lm in 177 cm width / 40 lm in 267 cm width

-

tensile strength (warp/weft)

310/210 daN/ 5 cm

EN ISO 1421

tear strength (warp/weft)

45/20 daN

DIN 53.363

flame retardancy

B-s2,d0/EN 13501-1

M1/NFP 92-507 • B1/DIN 4102-1• BS 7837 • BS 5867 • Schwerbrennbar Q1-Tr1/

ONORM A 3800-1 • Classe 1/UNI 9177-87 • M1/UNE 23.727-90 • VKF 5.3/SN 198898 •1530.3/AS/NZS • G1/GOST 30244-94 • Method 1/NFPA 701 • CSFM T19 • Class A/ASTM E84 • Group 1/AS/NZS 3837 • Class 1/EN 13773 • CAN/ULC-S109

-

warranty

2 years

-
